Middle clamps with grounding pin

The main function of module fixings is to clamp the solar modules, but the optical values should not be neglected. Like all other products, the varista® module clamps are extruded from high-quality aluminum. The use of EN AW 6063 T66 material ensures durability. Thanks to the variety, all module frame heights can be covered. We also deliver our middle and end clamps as individual items. These can also be used universally with other systems.

‍

• High-quality aluminum middle clamps
• Area of application: between two modules
• integrated earthing pins on the bottom of the clamp
• black anodized surface for black module frames
• Equipped with a universal mounting button for easy installation on all types of PV rails
• Distance between PV modules: 20 mm
• Screw drive: TX40
• Tightening torque: 14 Nm
